Tangshan 10m high pole light

by:Litel Technology     2022-05-24
Light pole parameters: 1. Height 10 meters, special-shaped pole, arm thickness 3.5mm, flange 320×320×16 (hole diagonal 260) 2. Material: Q235 steel 3. Hot-dip galvanizing: smooth and beautiful surface, thickness ≥ 75um, no peeling or peeling after the hammer test. 4. Plastic spray: using outdoor pure polyester plastic powder, the thickness is ≥80um, the quality of the plastic layer is stable, and it will not fade or fall off. 5. All fixing bolts and nuts are made of stainless steel (except anchor bolts and nuts). 6. The cable threading channel inside the light pole is unobstructed and easy to thread. 7. The light pole meets the requirements of lightning protection and grounding, ambient temperature: -15-50 degrees Celsius; ambient wind speed: 36m/s; seismic intensity: 8; corrosion resistance: 30 years. 8. Light source: a total of 100 watts led flood light.
